Budget 42mm Curved Acoustic Panels 1.6m High
Dispatched within 7 Working Days
- Includes set of Stabilising feet & 2 way link strip.
- Finished with durable plastic edging - Available in Black or Grey
- The Curve screens are 1131mm wide, 800mm deep.
- Height - 1.6m / 5.2ft
- Manufactured with an 18mm solid core
- Budget Screens have 12mm acoustic foam both sides
- Total screen thickness = 42mm
About the Budget Curved Acoustic Panels at 1.6m High
The Budget curve is part of the cost effective acoustic office range, making it feasible to add acoustic support to an open space regardless of budgets. Our curved screen variation is often used as a corner panel as this takes away any harsh corners and softens the look of a pod, meeting room or individual work area.
Following the same design as the rest of the Budget acoustic panels, the edges are complete with a black or grey PVC edging as well as a linking channel. The linking feature ensures the entire Budget range fits together to create bespoke configurations suitable for the available space, whilst creating the right shape.
The soft appearance of the curve is emphasized with a wide range of fabrics from the Woven range. Choose the right fabric to compliment any current office designs, or take the chance to add a new colour, making the space modern and relevant. 12mm acoustic foam is applied to both sides of the core, creating a sound absorbing panel that will excel in areas with high volumes.
Once the acoustic panels have been set up, place into areas of concern and watch as noise reduces and the spaces becomes a comfortable place to be.
What are the benefits?
- Cost effective office screens
- Includes 12mm acoustic foam
- Compatible with full Budget range
- Linking panel design
- Wide selection of fabrics
All office screens are made in the UK, by Rap Industries.
Product specifications for the Budget Acousic & Pinnable Office Screen range.
Screen Measurements
Acoustic screen thickness (Core, foam & fabric) - 42mm
Pinnable Screen thickness (Core & fabric) - 36mm
Foot slots in the frame are 290.5mm in from each end (Varied on screens 800mm W & smaller)
Wave Screens Only - 300mm Drop
Materials
Edging - PVC
Stability feet - Steel
*stability feet are trip and wheelchair friendly
Feet raise the screen by 25mm and protrude 230mm from either side of the screen
Castor wheels (upgrade or as part of Budget portable) Raise screen by 77mm & protrude 255mm each side of screen
Round Bases (upgrade) 200mm diametre
Acoustic
Internal - 18mm solid core
Foam - 12mm fire retardant acoustic foam
Pinnable
Internal – 18mm solid core + 8mm pinnable board either side
Linking strips - Flexible PVC
Fire Safety Elements
Foam
12mm Combustion Modified Foam BS 5852-2: using ignition Source 5 Crib
Chipboard
Surface spread of Flames Class 2 tested to BS479-7
MDF
Surface spread of Flames Class 2 tested to BS479-7
Plastic Components
Manufactured using non-flammable, self-extinguishing plastic.
Steel
Components are not considered to be a fire hazard.
Fabric
Woven Fabric
Woven Collection has been tested to BS 5867-2: 2008 & BS 7176 2007
Universe Fabric
Universe Collection has been tested to BS 5867-2: 2008 Type B
What variations of the Budget Screen are available?
The Budget Office Screen has a straight, curve, wave and portable style.
All the styles can be used together, enabling the ability to create a custom acoustic screen configuration.
Are the feet supplied with each screen?
Each Budget partition is supplied with a linking strip and set of stability feet (or castors wheels with the Budget Portable). The supplied stability feet are trip and wheelchair friendly, making them safe for all spaces.
How long will delivery take?
The standard lead time for dispatch is 7 working days, but if you’re in a hurry we do have an express option which reduces the lead time down to 5 working days. We need this amount of time to manufacture the screen to suit the chosen size, style and fabric colour.
Delivery can then take 1-3 working days, dependent on the chosen delivery service.
Will the Budget Screen help with noise?
The Budget range uses acoustic foam on both sides of the screen, which is useful when wanting to reduce noise. Loud environments can cause disruptions, adding acoustic partitions will eliminate unwanted noise and create a quieter working environment.
